PRODUCTS / SHARKCAGE / LOCKERS / QUADLOCKER CWL

CODE

SC-TL-WL-QD-02

QUADLOCKER CWL

The QUAD LOCKER has four individually lockable compartments with hinged doors. Available with optional plated sides and back. Add blocking and bracing kits to set up a 20ft container with open center aisle.

External dimension

(Width / Depth / Height)

57 '' / 30 '' / 83''

Weight

580lbs

Capacity

5000lbs

Shelf Capacity

300lbs

NSN

8145-01-512-0919

Material

HDG Steel

Stackability

2 high when not in active use

Opening (Width / Height)

24''

36''

Shelves

4 compartments - 2 levels in each

Shelf Positions

metric / US (imperial)

Popular Accessories

CW BLOCK AND BRACE KIT FOR ONE CAGE

Recomended QUANTITY
1 EA

CWL QUADLOCKER BLUE PLATES

Recomended QUANTITY
1 EA

Universal wheel kit

Recomended QUANTITY
1 EA

Platform Fit

TRICON I

QTY: 1 EA

Footprint Utilization: 82%

TRICON I

External dimensions (W / D / H) [in]:
77 / 96 / 96

Internal dimensions (W / D / H) [in]:
74 / 90 / 89

Door opening (W / H) [in]:
74 / 85

Deviation from standard: Doors on one end

10ft x 8ft BICON

Footprint Utilization: 63%

10ft x 8ft BICON

External dimensions (W / D / H) [in]:
57 / 118 / 96

Internal dimensions (W / D / H) [in]:
92 / 112 / 89

Door opening (W / H) [in]:
92 / 83

40ft HC (High Cube)

QTY: 16 EA

Footprint Utilization: 60%

40ft HC (High Cube)

External dimensions (W / D / H) [in]:
96 / 480 / 114

Internal dimensions (W / D / H) [in]:
92 / 474 / 106

Door opening (W / H) [in]:
92 / 102

Deviation from standard: Higher than the standard 40'

40ft standard shipping container

QTY: 16 EA

Footprint Utilization: 60%

40ft standard shipping container

External dimensions (W / D / H) [in]:
96 / 480 / 102

Internal dimensions (W / D / H) [in]:
92 / 474 / 93

Door opening (W / H) [in]:
92 / 89

Features

Hinged doors

Heavy duty hinged doors for easy access to items.

Custom interiors

Add custom fasteners or holders to improve organization and simplify content security.

Full container access

Access all content in the container from center aisle without downloading the cages.

BLOCK & BRACE

Integrated system to secure cages during transport and enable access to all contents of the container by leaving the center aisle open as defined by MIL-STD-107J and -1186A.
