CODE

SC-BA-XL-GT-01

TACTICAL BASKET XL

Gas spring assisted top lid and detachable front gate that are secured with one standard padlock. The gate can be used to roll tents, covers and other bulky material into the cage, or to simplify walking into the cage when stacking equipment like parachutes.

( Width / Depth / Height )

84 '' / 52 '' / 43''

Weight

660lbs

Capacity

4000lbs

Shelf Capacity

1000lbs

NSN

8145-01-499-0718

Material

HDG Steel

Stackability

4 high

metric / US (imperial)

Popular Accessories

Heavy Duty Cable Holder for Tactical Basket XL

Recomended QTY, LONG SHELF
1 EA

Recomended QTY, SPLIT SHELF
3 EA

Universal wheel kit

Recomended QUANTITY
1 EA

Platform Fit

M3 CROP

QTY: 4 EA

Footprint Utilization: 90%

M3 CROP

External dimensions (W / D / H) [in]:
91 / 230 / 10

Internal dimensions (W / D / H) [in]:
89 / 217 / 74

Deviation from standard: Fits inside container

Note: Inside dimensions are usable space with access tie downs, height is limitation

10ft x 8ft BICON

QTY: 2 EA

Footprint Utilization: 85%

10ft x 8ft BICON

External dimensions (W / D / H) [in]:
57 / 118 / 96

Internal dimensions (W / D / H) [in]:
92 / 112 / 89

Door opening (W / H) [in]:
92 / 83

463L Air Pallet

QTY: 4 EA

Footprint Utilization: 1%

463L Air Pallet

External dimensions (W / D / H) [in]:
108 / 88 / 2

Internal dimensions (W / D / H) [in]:
104 / 84 / 89

Note: Internal dimensions are usable space with open tie downs

20 ft standard shipping container

QTY: 8 (stacked 2 high) EA

Footprint Utilization: 1%

20 ft standard shipping container

External dimensions (W / D / H) [in]:
96 / 238 / 102

Internal dimensions (W / D / H) [in]:
92 / 231 / 93

Door opening (W / H) [in]:
92 / 89

40ft HC (High Cube)

QTY: 18 EA

Footprint Utilization: %

40ft HC (High Cube)

External dimensions (W / D / H) [in]:
96 / 480 / 114

Internal dimensions (W / D / H) [in]:
92 / 474 / 106

Door opening (W / H) [in]:
92 / 102

Deviation from standard: Higher than the standard 40'

40ft standard shipping container

QTY: 18 EA (stacked 2 high)

Footprint Utilization: %

40ft standard shipping container

External dimensions (W / D / H) [in]:
96 / 480 / 102

Internal dimensions (W / D / H) [in]:
92 / 474 / 93

Door opening (W / H) [in]:
92 / 89

TRICON I

QTY: 1 EA

Footprint Utilization: %

TRICON I

External dimensions (W / D / H) [in]:
77 / 96 / 96

Internal dimensions (W / D / H) [in]:
74 / 90 / 89

Door opening (W / H) [in]:
74 / 85

Deviation from standard: Doors on one end

TRICON II

QTY: 1 EA

Footprint Utilization: %

TRICON II

External dimensions (W / D / H) [in]:
77 / 96 / 96

Internal dimensions (W / D / H) [in]:
74 / 88 / 88

Door opening (W / H) [in]:
74 / 85

Deviation from standard: Doors on both ends

Features

Top and side access

Access content either through the top lid or front gate, depending on content type and operating environment constraints.

Multiple door configurations

Select from hinged doors or panels when customizing your cage.

Toplift

Reinforced corner post and connection points to accommodate crane, helicopter lift and UNREP according to MIL-STD- 913A, -209K and -648D. Weld seams inspected according to RCX-3 to ensure safety.

Forkliftable

4-way forklift capability compatible with most pallet jacks and forklifts. Designed to fulfill both the STANAG-2828 and 2829, as well as MIL-STD-648D, to ensure operability in joint operations.

Stackable

Self-centering corners to ensure safety and efficiency in stacking.

Land-sea-air

Strong enough for all modes of strategic transport, designed according to MIL-STD- 1791D, -1366E and STANAG-3400.

Intermodal

Transition seamlessly from one mode of transport to the next according to the definition in MIL-STD-3028.

Content Visibility

See-through grid enable content visibility at all times. Covers available to temporarily limit visibility.

Lockable

Lock using standard issue series 5200 padlocks.

TACTICAL BASKET MEDIUM

( Width / Depth / Height )

70 '' / 41 '' / 39''

Perfect fit for TRICON containers, with full gate front and gas lift assisted top opening.

LOCKER BASKET XL

( Width / Depth / Height )

84 '' / 52 '' / 81''

Perfect fit for 10ft, 20ft and 463L pallet, with gated bottom for bulky items and double doors and shelves above for accessories.
